CW325
0.098"(2.50mm)Pitch Single Row Headers - Pin Header
CW325 Series * Ploes : 2-20 * Material : Insulator : NYLON UL 94V-2 * Contact : 0.64mm(.025") Square Pin,Brass, Tin Plated 60u" * Mates With CH325 Series Housing Specifications * Current Rating : 3A AC, DC * Voltage Rating : 250V AC, DC * Temperature Range : -25℃ ~ +85℃ * Insulatipn Resistance : 1,000MΩ Min. * Withstand Voltage : 1,000 AC / Minute * Applicable PC Board Thickness : .063"(1.6mm)
